Advantages:

1. high accuracy, generally up to ± 1% R, ± 0.5% R, high precision type up to ± 0.2% R;

2. good repeatability, short-term repeatability of up to 0.05% to 0.2%, is because good repeatability, such as frequent calibration or online calibration can be obtained with very high accuracy, in the trade settlement is the preferred choice of flowmeter

3. output pulse frequency signal, applicable to the total amount of measurement and connection with the computer, no zero drift, anti-interference ability;

4. can obtain a very high-frequency signal (3 ~ 4kHz), signal resolution;

5. range of degree models, medium and large caliber up to 1:20, the small diameter of 1:10;

6. compact and lightweight structure, easy installation and maintenance, large circulation capacity;

7. applicable to high-pressure measurement, the meter body does not have to open holes, easy to make high-pressure type instrument;

8. special sensor type, according to the user’s special needs for various types of special sensors, such as low-temperature type, two-way type, downhole type, sand mixing special type, etc.;

9. can be made into insertion type, suitable for large-diameter measurements, small pressure loss, low price, can be taken out without flow, installation, and maintenance. It can be taken out without stopping the flow, easy to install and maintain.

Features:

•  Non-blocking design
  The entire sensor and liquid contact parts are made of stainless steel, with a simple structure, no moving parts, and holes, gaps and gaskets that are prone to failure are avoided as much as possible.
• Mechanical anti-vibration treatment
  In terms of anti-vibration treatment, our company has optimized the circuit part to effectively filter out the vibration frequency caused by mechanical vibration.
• Simplify troubleshooting
  The sensor is isolated from the process, easy to install, constant instrument coefficient, high data repeatability, good interconversion between the converter and the sensor, and convenient and fast maintenance process
• Analog and digital signal processing
  The converter adopts advanced circuit design, and can adopt analog mode with manual setting on site and digital processing mode with adaptive function. It has no zero drift, high accuracy, wide measuring range, and commonly used range ratio is 8:1, and the maximum range ratio is 15:1.
