Advantages:
1. A wide range of measurement media can be used to measure oil, water, and corrosive media.
2. High accuracy, accuracy can reach 0.1%, using high-quality pressure sensors and circuits, with high reliability and stability. Good linearity and high-temperature stability.
3. Good quality, good waterproof performance, and long service life.
4. Small size, lightweight, convenient installation and debugging, just connect it to a pipeline or container, easy to use, and easy to maintain
5. Strong anti-interference ability and long transmission distance. 4-20mA DC two-wire signal transmission with strong anti-interference ability and long transmission interval
6. The pressure sensor directly senses the pressure of the measured liquid level and is not affected by medium foaming or sedimentation.
7. Stainless steel fully sealed shell with good waterproof performance;
8. Aluminum alloy die-casting shell, three-terminal isolation, electrostatic spraying maintenance layer, sturdy and durable.
Features:
- Imported key parts, stable performance, reliable quality, and affordable price
- Adjustable damping (electrical damping is 0-6S)
- The minimum loop resistance required for communication is 250Ω. Full range of specifications: The range is from 0~125Pa to 0~40MPa, you can choose any
- Positive and negative migration: positive migration 500%, negative migration 600%
- Output signal: two-wire 24VDC power supply, 4-20mADC output (can also be four-wire 220VAC power supply, 0-10mADC output)
- Explosion-proof: Intrinsically safe type iallCT6, Flameproof type dIIBT4
- Good pressure resistance: general pressure resistance 14MPa. High static pressure resistance 32MPa
- Corrosion resistance: We can provide corrosion-resistant transmitters made of 316L, monel, hastelloy, tantalum and other materials
