Advantages:
1. Low pressure loss. The sensor structure is simple and reliable, and it will not damage the flow field and thus not change the flow state of the measured fluid. Moreover, the sensor has the same cross-sectional area as the pipe diameter and is lined with smooth and wear-resistant materials, avoiding wear, and blockage, and greatly reducing operating power consumption.
2. Corrosion resistance. Due to the use of insulating materials for the lining of the inner wall of the measuring tube and the chemical passivation of the measuring electrode surface, it is possible to measure general corrosive fluids as long as the lining material is selected appropriately.
3. Wide range of measurement. When using the same type of electromagnetic flow meter sensor for full range flow rate measurement, the maximum diameter used can reach 3m and the minimum can reach the millimeter level, which greatly expands the applicable range of electromagnetic flow meters.
4. Strong adaptability. The measurement output of an electromagnetic flowmeter is the average flow velocity of the fluid cross-section, and the calibration process does not have high requirements for the type of fluid substance being measured. The electric field flowmeter meets the requirements of green environmental protection and is easy to install and maintain. The output of measured values does not involve the dynamic inertia of the fluid, and the response is sensitive and can measure instantaneous flow.

Features:

• Not affected by changes in fluid density, viscosity, temperature, pressure and electrical rate, linear measurement
• The principle can achieve high-precision measurement;
• There is no flow blocker in the measuring tube, the pressure loss is small, and the straight pipe section requirement is low;
• The nominal diameter covers a wide range from DN10 to DN2000, and there are many options for lining and electrodes.
• Can meet the requirements of measuring a variety of conductive fluids;
• The converter uses programmable frequency low frequency rectangular wave excitation to improve the stability of flow measurement.
• Qualitative, small power loss;
• The converter uses a 16-bit embedded microprocessor, full digital processing, fast operation speed, and anti-
• Strong interference ability, reliable measurement, high accuracy, flow measurement range can reach 50:1;
• High-definition backlit LCD display, full Chinese menu operation, easy to use, simple operation
• Simple, easy to learn and understand;
• With RS485 or RS2320 digital communication signal output.
