Advantages:

1. Widely used for measuring the differential pressure (or pressure), level, and density of liquid, gas, or steam and converting the value of the above into current signal output or digital protocol output.
2. The pressures are directly applied to the isolating diaphragm which provides isolation and resistance against process fluid corrosion.
3. Being microprocessor-based, the electronic circuit is extremely versatile and accurate.
4. Combined with sensor precision, it provides high accuracy and range ability.
5. Transmitter performance is improved by continuous monitoring of the sensor temperature and corresponding corrections.
6. Local display easy to read and write data.

Features:

• Imported key parts, stable performance, reliable quality, and affordable price
• Adjustable damping (electrical damping is 0-6S)
• The minimum loop resistance required for communication is 250Ω. Full range of specifications: The minimum range is from 0~125Pa to the maximum 0~40MPa, optional
• Positive and negative migration: positive migration 500%, negative migration 600%
• Output signal: two-wire 24VDC power supply, 4-20mADC output (can also be four-wire 220VAC power supply, 0-10mADC output)
• Explosion-proof: Intrinsically safe type iallCT6, Flameproof type dIIBT4
• Good pressure resistance: general pressure resistance 14MPa. High static pressure resistance 32MPa
• Corrosion resistance: We can provide corrosion-resistant transmitters made of 316L, monel, hastelloy, tantalum and other materials
